Basic Product Information
Product Type: Communication_Module (10BaseT Ethernet Module)
ABB Type Designation: EI 813F
Product ID: 3BDH000022R1
Catalog Description: EI 813F Ethernet Module 10BaseT
Long Description: EI 813F, Ethernet Module 10BaseT (Twisted pair)
Medium Description: Ethernet Module EI 813F, 10BaseT, for Freelance AC 800F
Key Compatibility Requirements:
Must be used with ABB PM 802F or PM 803F controllers (not compatible with other controller models).
Requires ABB software version V7.1SP2a or higher for proper functionality (mandatory for system integration and network communication).
Battery Requirement: 0 (no internal batteries needed for operation, reducing maintenance needs).
Product Categories:
Control System Products ￫ Control & Communication ￫ AC 800F ￫ AC 800F - Communication Modules ￫ EI 813F Ethernet Module 10BaseT
Control Systems ￫ Freelance ￫ Controllers ￫ AC 800F Communication Modules ￫ EI 813F
Core Specifications
1.Network & Communication Parameters
Ethernet Standard: 10BaseT (Twisted Pair) – supports 10 Mbps data transfer rate, half-duplex operation, and uses unshielded twisted-pair (UTP) cabling (compliant with IEEE 802.3 standard for Ethernet).
Network Role: Serves as a network interface for PM 802F/PM 803F controllers, enabling communication with Ethernet-connected devices (e.g., operator workstations, SCADA systems, other controllers in the AC 800F network).
2.Physical Dimensions & Weight
Product Net Length: 125 mm
Product Net Height: 155 mm
Product Net Width: 28 mm (compact form factor optimized for installation in AC 800F controller racks, saving space for other modules).
Product Net Weight: 0.15 kg (lightweight design reduces rack load and simplifies handling during installation or replacement).
3.Origin & Regulatory Compliance
Countries of Origin: Malta (MT) and Germany (DE)
Customs Tariff Number: 85389091 (classified as parts for industrial control apparatus under global customs standards).
RoHS Status: Not RoHS Compliant (does not meet EU Directive 2011/65/EU restrictions on hazardous substances; users should verify regional regulatory requirements before deployment).
WEEE Category: 5 (Small Equipment) – defined as equipment with no external dimension exceeding 50 cm, ensuring compliance with waste electrical and electronic equipment recycling regulations.
Key Application & Functional Notes
System Integration: Designed exclusively for ABB’s Freelance AC 800F control system, it integrates seamlessly with PM 802F/PM 803F controllers via the system backplane. This plug-and-play compatibility eliminates the need for complex external wiring between the module and controller, streamlining installation.
Data Transmission: Enables critical data exchange between the controller and Ethernet networks, including process control signals, status updates, and configuration commands. The 10BaseT standard ensures reliable communication over typical industrial wiring distances (up to 100 meters with UTP Cat3 or higher cabling).
Software Dependency: The mandatory use of software V7.1SP2a or higher ensures compatibility with AC 800F system features, such as network management, data logging, and remote monitoring. Users must update system software to this version (or later) to avoid communication errors or functionality gaps.
Industrial Suitability: Ideal for industrial environments where Ethernet is the primary network protocol for control systems. Its compact size and controller-specific design make it suitable for both small-scale skid-mounted systems and large-scale plant-wide AC 800F deployments.
