➪Brand/Manufacturer: ABB
➪Part number:PM856K01 3BSE018104R1
➪Country of origin: Sweden
➪Condition:New with 1 year warranty
➪About shipping:DHL,UPS,FedEx,and TNT
➪Payment:100% T/T for stock items before shipping
Basic Product Identification
Model & Article Number: Model PM856K01, corresponding article number 3BSE018104R1; exchange
number EXC3BSE018104R1.
Product Category: Processor Unit Kit, classified as spare parts, belonging to ABB’s AC 800M
controller series (compatible with 800xA and Compact Product Suite platforms).
Commercial Status: "No longer for sale" (discontinued) and replaced by a new product (specific
replacement model not detailed in the document).
Origin & Customs Information: Country of origin Sweden (SE); customs tariff number 85389091.
Package Composition
The kit is a integrated package containing multiple core components for controller deployment:
CPU Module: PM856 (article number 3BSE018128R1).
Baseplate: TP830 (width 115 mm, article number 3BSE018114R1).
Terminators: TB850 (CEX-bus terminator, article number 3BSC950193R1); TB807 (ModuleBus
terminator, article number 3BSE008538R1).
Memory Backup: Lithium battery (article number 4943013-6, weight 9 g, portable type).
Accessories: 4-position power plug (article number 3BSC840088R4); fuses (2 A: 3BSC770001R47; 3.15
A: 3BSC770001R49).
Technical Specifications
Dimensions: Net height 200 mm, net width 130 mm.
Weight: Net weight 1.1 kg.
Battery Details: 1 lithium battery (portable type), weight 9 g, used for memory backup to preserve
data during power-off.
Product Classification & Compatibility
Platform Compatibility: Applicable to ABB’s 800xA and Compact Product Suite control systems,
compatible with multiple AC 800M hardware versions (2.1/SB2, 4.0, 4.1, 5.0, 5.1) and categorized
under "Central Units" for controllers.
WEEE Category: Classified as 5. Small Equipment (no external dimension exceeding 50 cm), subject to
relevant waste disposal regulations.
