>> Key Advantages & Features
High-Speed Processing Capability
Equipped with a 1.2 GHz multi-core processor, the module executes 64-bit control logic at a rate of 100,000 steps per millisecond—30% faster than previous generations. This speed enables precise control of complex processes, such as multi-loop temperature regulation in chemical reactors, ensuring tight process tolerance within ±0.1°C.
Scalable System Integration
Supports up to 4096 I/O points and 1000 control loops, with expandable memory (8 GB RAM, 64 GB flash) for large program storage. It seamlessly integrates with Yokogawa’s ProSafe-RS safety system and field devices via FOUNDATION Fieldbus, HART, and PROFINET, reducing integration time by 25% in retrofitted plants.
Enhanced Reliability with Redundancy
Offers dual-redundant configuration with automatic failover (switchover time <50 ms), achieving 99.999% availability. This design ensures uninterrupted operation in critical applications like offshore oil platform control, where downtime could cost millions in production losses.
Advanced Diagnostic & Cybersecurity
Features real-time self-diagnostics for hardware faults, communication errors, and process anomalies, with alerts displayed on CENTUM VP’s HMI. Incorporates IEC 62443-compliant security measures (role-based access, encrypted communication) to prevent unauthorized access—vital for protecting critical infrastructure.
Energy-Efficient Operation
Optimized power consumption (max 30 W) reduces heat generation by 20% compared to modules, extending component lifespan and lowering cooling costs in control rooms. Its fanless design minimizes maintenance needs in dust-prone environments like mining facilities.
>> Technical Parameters
Parameter | Specification |
Processor | 1.2 GHz multi-core 64-bit processor |
Memory | 8 GB RAM, 64 GB flash storage |
I/O Capacity | Up to 4096 points, 1000 control loops |
Execution Speed | 100,000 steps/ms (control logic) |
Redundancy | Dual-redundant (A/B switchover <50 ms) |
Communication Protocols | FOUNDATION Fieldbus, HART, PROFINET, Modbus TCP/IP |
Operating Voltage | 24 VDC ±10% |
Power Consumption | Max 30 W (per module) |
Operating Temperature | 0°C to 55°C (32°F to 131°F) |
Dimensions (W×H×D) | 150mm × 220mm × 300mm (5.91" × 8.66" × 11.81") |
Weight | Approx. 1.8 kg (3.97 lbs) |
Certifications | CE, UL, ATEX, IECEx, IEC 61508 (SIL 2) |
>> Product Uses
1. Oil Refining & Petrochemicals
Controls distillation columns, catalytic crackers, and blending processes. Its high-speed processing optimizes crude oil separation efficiency, increasing yield by 1.5% in large refineries.
2. Power Generation
Manages boiler combustion, turbine speed, and grid synchronization in thermal power plants. Ensures stable power output with load-following accuracy of ±0.5% rated capacity, supporting grid frequency regulation.
3. Chemical Manufacturing
Oversees batch and continuous processes (e.g., polymer production), with precise control of reactant flow, pressure, and temperature. Reduces batch cycle time by 10% through optimized sequence execution.
4. Liquefied Natural Gas (LNG) Facilities
Controls refrigeration cycles and storage tank levels in LNG plants. Its redundancy ensures safe operation during low-temperature (-162°C) processes, preventing equipment damage from thermal stress.
5. Water & Wastewater Treatment
Automates filtration, chemical dosing, and sludge processing. Optimizes energy use in pump systems, cutting operational costs by 8% while maintaining compliance with environmental discharge standards.
