Emerson KJ3001X1-BJ1 is a DeltaV Output Module, designed to convert DCS control signals into actionable outputs for field devices. It supports stable signal transmission, has overload protection, and ensures seamless integration with DeltaV systems for industrial automation.
ATEX Instruction Sheet Part Number: Aligns with Emerson DeltaV I/O module series standards (typical
format: D80xxxxX0xx; specific number to confirm via product label)
Typical Publication Date: Consistent with DeltaV I/O hardware documentation (e.g., 2010–2022, final
date via product label)
Manufacturer: Emerson Process Management / Automation Solutions (Austin, Texas / Round Rock,
Texas, USA)
Serial Number & Manufacturing Details: Refer to the product label for serial number, manufacturing
location, and manufacturing date
Product Overview
The KJ3001X1-BJ1 is a DeltaV Output Module engineered for industrial automation and hazardous environments, dedicated to converting control signals from DeltaV systems into actionable outputs for field devices (e.g., solenoid valves, relays, actuators). It ensures stable, reliable signal transmission in process control scenarios (oil & gas, chemical, pharmaceutical) and complies with global hazardous area safety standards, supporting seamless integration into DeltaV automation ecosystems.
Environmental Specifications
Environmental Parameter
Specification
Ambient Temperature
-40°C to +70°C (wide range for extreme cold/hot industrial sites)
Shock
10 G ½-sinewave for 11 ms (withstands transportation/on-site impacts)
Vibration
1 mm peak-to-peak from 5 Hz to 16 Hz; 0.5 g from 16 Hz to 150 Hz (stable under machinery vibration)
5% to 95% non-condensing (adapts to humid environments like chemical plants)
Integration with DeltaV DCS
The KJ3001X1-BJ1 is fully compatible with DeltaV system architecture, featuring:
Rack-Mount Design: Fits standard DeltaV I/O racks, enabling seamless integration into existing cabinets without additional modification.
Power Distribution: Connects to the DeltaV Local Bus to distribute power to downstream modules, ensuring uniform voltage across the system.
Status Monitoring: Includes LED indicators for "Power ON" (green) and "Fault" (red) to provide visual confirmation of operational status. Fault signals can be routed to the DeltaV controller for remote alerting.
Redundancy Support: Can be configured in redundant pairs (1+1) to eliminate single points of failure, critical for safety instrumented systems (SIS) and high-availability applications.
Safety & Compliance
Certifications: Complies with IEC 61010-1 (safety for electrical equipment for measurement, control, and laboratory use) and UL 61010-1 (North American safety standard).
Hazardous Area Ratings: Suitable for general industrial environments (non-hazardous); for Zone 2/Division 2 applications, refer to Emerson’s hazardous-area power supply variants.
Installation Safety: Must be wired by qualified personnel per local electrical codes (e.g., NEC, IEC); input wiring requires proper grounding to prevent electrical noise and ensure safety.
Maintenance & Operation
No User-Serviceable Parts: Internal components are sealed and not field-serviceable; replacement is recommended for faults beyond self-recovery.
Lifecycle: Designed for a 100,000-hour MTBF (Mean Time Between Failures) under nominal operating conditions, minimizing maintenance requirements.
Replacement: When replacing, ensure the new module matches the same voltage and current ratings to avoid system incompatibility.
Application Scenarios
The KJ3001X1-BJ1 is ideal for:
Powering DeltaV I/O modules in process control loops.
Supporting controller redundancy setups in critical processes.
Integration into new DeltaV installations or retrofits of legacy systems.
Industrial environments requiring stable DC power with robust fault protection.
Documentation & Support
Key Manuals: Refer to Emerson’s DeltaV Power Supply Installation Guide (Document No. 12P2046) and DeltaV System Hardware Reference for wiring diagrams and integration steps.
Support: Available through Emerson’s global service network, including technical hotlines and on-site assistance for installation and troubleshooting.
This power supply module is a reliable cornerstone of DeltaV DCS infrastructure, ensuring uninterrupted operation of critical automation components in demanding industrial settings.
Safety Warnings
Output Current Limits: Do not exceed 2 A per channel or 8 A total (prevents module damage, overheating,
or fire risks in hazardous areas).
Field Wiring: Use shielded cables for output connections to reduce electromagnetic interference (ensures
reliable control of critical field devices).
