204-040-100-013 Advantages
The 204‑040‑100‑013 Back Plane Rack stands out from comparable rack chassis accessories in several key areas.
Integrated backplane bus design. The 204‑040‑100‑013 Back Plane Rack adopts integrated internal backplane circuit, realizing automatic signal interconnection between each slot, greatly reducing complicated external wiring work inside monitoring cabinets.
Multi‑slot modular expandable architecture. The 204‑040‑100‑013 Back Plane Rack provides multiple standard slots, users can flexibly configure and expand different functional monitoring modules according to actual field‑monitoring channel requirements.
Support hot‑swap for compatible plug‑in modules. The 204‑040‑100‑013 Back Plane Rack keeps backplane power and bus signal intact when replacing qualified functional modules; technicians can swap modules without powering‑off the whole rack system.
Rugged metal mechanical frame. The 204‑040‑100‑013 Back Plane Rack uses high‑strength metal frame structure, offering stable mechanical fixation and basic electromagnetic‑shielding performance for all inserted modules under industrial vibration environment.
Centralized power distribution function. The 204‑040‑100‑013 Back Plane Rack distributes input power to each module slot through internal circuit, simplifying power‑supply wiring for multi‑card monitoring systems.
Original system‑matching hardware. As factory‑original component, the 204‑040‑100‑013 Back Plane Rack perfectly mates with matched‑series monitoring modules without extra adapter or custom modification.
Standard cabinet‑mount installation. The 204‑040‑100‑013 Back Plane Rack fits standard industrial cabinet installation dimensions, convenient for layout inside various industrial control cabinets.
204-040-100-013 Applications
Power Generation Plants. System backplane rack for machinery monitoring systems, the 204‑040‑100‑013 Back Plane Rack holds signal‑processing and interface modules for turbine and generator condition‑monitoring cabinets.
Petrochemical & Refinery Facilities. The 204‑040‑100‑013 Back Plane Rack serves as core chassis hardware for compressor and expander machinery‑protection monitoring cabinets in large‑scale chemical‑process plants.
Heavy‑Industry Manufacturing Sites. The 204‑040‑100‑013 Back Plane Rack acts as key rack‑mount component inside equipment‑monitoring control cabinets, supporting multi‑channel online condition‑monitoring for high‑speed rotating critical machinery.
Energy & Utility Premises. The 204‑040‑100‑013 Back Plane Rack delivers dependable backplane bus transmission and mechanical support for rotating‑machinery monitoring modules under complex industrial‑site operating‑condition environments.
Off‑shore & Process Plant Facilities. The 204‑040‑100‑013 Back Plane Rack provides stable rack‑based system deployment for machinery‑monitoring hardware in industrial‑site control‑room cabinet environments.
204-040-100-013 Certifications & Compliance
The 204‑040‑100‑013 Back Plane Rack holds the following international safety and compliance approvals:
CE Certification — European industrial‑equipment safety and electromagnetic compatibility approval.
RoHS Certification — Restriction of hazardous substances standard for electronic and electrical equipment.
All back‑plane racks supplied are 100% new original parts. Every 204‑040‑100‑013 Back Plane Rack unit is functionally tested before dispatch, packed in professional anti‑static packaging, and covered by a one‑year warranty from the date of delivery.
