Core Product Overview
| Attribute | Details |
| Product Model | ABB PM866AK01 |
| Product Type | Compact Controller |
| Manufacturer | ABB |
| Target System | ABB AC 800M Control System |
| Primary Function | Industrial process control, modular automation, and scalable system integration |
Description:The ABB PM866AK01 (Product ID: 3BSE076939R1) is a high-performance compact
controller designed for the AC 800M control system, delivering fast processing speeds and flexible
connectivity for industrial automation applications. Equipped with redundant Ethernet ports, modular
expansion capabilities, and ISA Secure certification, it balances reliability, ease of configuration, and
robust environmental resilience. Below is a structured, visually refined breakdown of its core
specifications, functional features, and technical attributes.
Physical & Environmental Specifications
| Specification | Details |
| Dimensions | - Width: 119 mm (4.7 in.) - Height: 186 mm (7.3 in.) - Depth: 135 mm (5.3 in.) - Weight (with base): 1200 g (2.6 lbs) |
| Environmental Conditions | - Operating Temperature: 0 to +55 °C (+32 to +131 °F) - Storage Temperature: -40 to +70 °C (-40 to +158 °F) - Temperature Change Rate: 3 °C/min (IEC/EN 61131-2) - Altitude: Up to 2000 m (IEC/EN 61131-2) - Relative Humidity: 5–95% (non-condensing) - Pollution Degree: 2 (IEC/EN 61131-2) - Corrosion Protection: G3 (ISA 71.04) |
| Mechanical Resilience | - Vibration: 10–50 Hz (0.0375 mm amplitude); 50–150 Hz (0.5 g acceleration); 5–500 Hz (0.2 g acceleration) - Emitted Noise: <55 dB (A) |
