Bently Nevada 132417-01 190662-26 4 Channel Monitor Solar Turbines

Bently Nevada 132417-01 / 190662-26: Description

The 132417-01 and 190662-26 are identified as complementary accessory components designed for the 3500 Machinery Protection System. These parts function as specialized interface, termination, or signal conditioning modules, working in tandem to enhance the connectivity, reliability, or safety compliance of 3500 Series monitor modules (e.g., 3500/40M Proximitor Monitor, 3500/42M Proximitor Seismic Monitor, 3500/25 Enhanced Keyphasor Module).

Their core role is to facilitate seamless signal transmission between field transducers (proximity probes, magnetic pickups, seismic transducers, or Seismoprobe devices) and the main 3500 monitor modules. Likely configured as a paired set (132417-01 as the primary interface module and 190662-26 as a complementary component such as a termination block adapter or signal booster), they address specialized application needs—including enhanced termination options, signal isolation, noise reduction, or compatibility with hazardous area deployments.

Engineered for form-fit-function integration with the 3500 Series rack system, these modules adhere to the brand’s rugged industrial standards, ensuring performance in harsh environments (e.g., power generation, oil & gas, manufacturing) with extreme temperatures, humidity, or electromagnetic interference (EMI). They support the 3500 Series’ modular philosophy, enabling retrofitting, system expansion, or maintenance without modifying existing rack infrastructure. By optimizing signal integrity, they complement key monitoring functions (vibration, speed, position, acceleration measurements) and ensure accurate data acquisition for machinery health monitoring and alarm triggering.

Key Parameters

Product Type: Complementary accessory components (interface/termination modules) for Bently Nevada 3500 Series Machinery Protection System.

Core Function: Enhance signal connectivity, conditioning, or termination between field transducers and 3500 Series monitor modules; support specialized needs such as hazardous area compliance, signal isolation, or high-reliability termination.

Compatibility: Exclusively compatible with 3500 Series monitor modules (3500/40M, 3500/42M, 3500/25, etc.) and 3500 Series racks; align with the system’s modular mounting and communication protocols.

Transducer Support: Designed for Bently Nevada transducers, including proximity probes, magnetic pickups, velocity transducers (Velomitor), acceleration transducers, and Seismoprobe devices (consistent with 3500 Series transducer compatibility).

Physical Dimensions: Conform to 3500 Series accessory form factors—estimated 241.3 mm × 24.4 mm × 99.1 mm (non-barrier configuration) or 241.3 mm × 24.4 mm × 163.1 mm (barrier configuration) (9.50 in × 0.96 in × 3.90 in / 6.42 in); combined weight estimated 0.40–0.92 kg (0.88–2.03 lb) for the paired set.

Rack Space Requirement: 1 full-height rear slot per module (consistent with 3500 Series I/O/accessory mounting standards).

Environmental Adaptability: Operating temperature range -30°C to +65°C (-22°F to +150°F) (non-barrier) or 0°C to +65°C (32°F to +150°F) (barrier); storage temperature -40°C to +85°C (-40°F to +185°F); humidity resistance up to 95% non-condensing.

Signal Handling: Input/output impedance aligned with 3500 Series standards (e.g., 10 kΩ for proximity/acceleration inputs, 21.8 kΩ for Keyphasor inputs); supports integration with -24 Vdc transducer power supply (consistent with 3500 Series power norms); short-circuit protected outputs for enhanced reliability.

Safety & Compliance: Inherit 3500 Series global certifications, including FCC Part 15, EU EMC Directive 2014/30/EU, EU LV Directive 2014/35/EU, and RoHS Directive 2011/65/EU; compatible with hazardous area deployments (Class I, Division 2/Zone 2) when paired with approved 3500 Series barrier configurations.

Integration: Support 3500 Rack Configuration Software for parameterization; seamlessly integrate with 3500 Series monitor functions (alarm setpoints, static value reporting, diagnostic data transmission).
