GE IS200DSPXH1CAA is a circuit board for Mark VIe systems, handling digital signal processing and I/O communication. It features isolation, diagnostics, -40°C to +70°C operation, EMC protection, and UL/CE compliance for reliable industrial control performance.
The GE IS200DSPXH1CAA is a high-reliability industrial circuit board engineered exclusively for GE’s
Mark VIe Distributed Control System (DCS)—a critical component designed to handle signal
processing, module-to-controller communication, and auxiliary control logic for mission-critical
industrial operations. Built to GE’s rigorous industrial standards, this board acts as a bridge between
Mark VIe I/O modules (e.g., analog/digital sensors) and central controllers, ensuring accurate data
transmission and stable performance in harsh environments. Ideal for sectors where system uptime
and signal integrity directly impact safety and productivity—such as power generation, oil & gas, and
heavy manufacturing—the IS200DSPXH1CAA delivers plug-and-play compatibility with the Mark VIe
ecosystem, reducing integration complexity and minimizing unplanned downtime.
Core Features
1. Seamless Mark VIe Integration
Plug-and-play design is automatically recognized by GE Mark VIe Configuration Studio and CIMPLICITY software—no custom coding or complex calibration required. Reduces installation time by 40% compared to generic industrial circuit boards, accelerating system commissioning.
2. High-Precision Signal Processing
Equipped with a 32-bit microprocessor and 16-bit analog resolution, the board ensures accurate conversion and transmission of sensor data (e.g., temperature, pressure, flow). Critical for applications like turbine bearing temperature monitoring or chemical reactor pressure control, where signal inaccuracies risk equipment damage.
3. Industrial-Grade Durability
Conformal Coating: Protects internal PCB components from moisture, dust, and chemical vapors (common in refineries or power plants), extending service life to 10+ years.
EMI Shielding: 2.5kV AC electrical isolation blocks electromagnetic interference from heavy machinery (e.g., motors, generators), preventing signal corruption.
Flame-Retardant Housing: UL 94 V-0 rating meets strict fire safety standards for industrial control cabinets.
4. Proactive Diagnostics
Color-coded LED indicators (power: green; communication: amber; fault: red) enable instant troubleshooting. Built-in self-test (BIST) functionality alerts operators to potential issues (e.g., voltage fluctuations, loose wiring) before they cause system downtime.
5. Hazardous Zone Readiness
ATEX/IECEx certification allows deployment in Zone 2 (flammable gas atmospheres) and Zone 22 (combustible dust environments), making it suitable for oil refineries, chemical plants, and grain processing facilities.
Applications
The IS200DSPXH1CAA is optimized for industries relying on GE Mark VIe DCS for critical control:
Power Generation: Gas/steam turbine auxiliary control (e.g., lubrication system monitoring), boiler feedwater sensor signal processing.
Oil & Gas: Wellhead pressure sensor data routing, pipeline flow meter signal conditioning, refinery distillation column control.
Heavy Manufacturing: Steel mill rolling mill sensor integration, cement plant kiln temperature signal processing, automotive assembly line I/O communication.
Water & Wastewater: Pump station level sensor data transmission, chemical dosing system auxiliary control.
Compatibility List
Category
Compatible Products
GE Mark VIe Components
IS200CPUH1A/IS200CPURH1A Controllers, IS200AEADH1A Analog I/O, IS200DIHCH1A Digital I/O, IS200VCRCH1A Power Supplies
GE Mark VIe Configuration Studio V9.0+, GE CIMPLICITY 11.0+, Modbus Poll (protocol testing), PROFIBUS DP Configurator
Why Choose GE IS200DSPXH1CAA
Genuine GE Quality: Engineered to match Mark VIe’s strict performance standards—avoids compatibility errors, signal loss, or premature failure common with third-party circuit boards.
Total Cost Savings: Reduces labor costs (faster installation) and maintenance expenses (10-year lifespan); eliminates the need for redundant backup boards in non-critical setups.
Reliability: Field-proven design with millions of operating hours in global industrial facilities—ensures uninterrupted performance in harsh conditions.
Global Support: Backed by GE’s 24/7 industrial service network—on-site technical support, 2-day spare parts delivery (North America/Europe), and remote troubleshooting via GE Digital Services.
Availability & Support
Stock Status: In stock (bulk orders of 5+ units qualify for 5–15% volume discounts)
GE Mark VIe DCS; Works with IS200 Series Controllers (IS200CPUH1A
IS200CPURH1A) and I/O Modules (IS200AEADH1A
IS200DIHCH1A
IS200DOCH1A)
Core Function
Signal conditioning (analog/digital)
controller-I/O data routing
and auxiliary control logic execution; Supports real-time data processing for industrial sensors/actuators
Electrical Ratings
Operating Voltage: 5V DC (powered via Mark VIe backplane); Voltage Tolerance: ±10%; Isolation: 2.5kV AC (EMI/RFI protection); Short-circuit protection for I/O channels
Signal Performance
Analog signal resolution: 16-bit; Digital signal response time: <1ms; Supports up to 200 concurrent signal points; Error rate: <0.001% (annualized)
Environmental Durability
Operating Temperature: -40°C to 70°C (-40°F to 158°F); Storage Temperature: -40°C to 85°C (-40°F to 185°F); Humidity: 5–95% (non-condensing); Vibration: IEC 61131-2 (5g
5–500Hz)
Material & Protection
Conformal-coated PCB (resists moisture
dust
and industrial chemicals); Flame-retardant plastic housing (UL 94 V-0); IP20 rating for cabinet installations; Gold-plated terminals (corrosion resistance)
Certifications
UL 508 (Industrial Control Equipment); CE (EN 61010-1); ATEX/IECEx (Zone 2/22 for hazardous areas); RoHS 2 compliant
Physical & Mounting
Dimensions: 140mm (L) × 85mm (W) × 26mm (H); Backplane-mounted (fits 19-inch Mark VIe I/O racks); Tool-less installation; Removable terminal blocks for easy wiring
