GE IS210DRTDH1A is an RTD Terminal Board for Mark VIe systems. It connects and conditions RTD sensors (e.g., Pt100), supports multiple channels, offers isolation, diagnostics, operates at -40°C to +70°C, meets UL/CE, ensuring accurate temperature measurement in industrial applications.
The GE IS210DRTDH1A is a specialized RTD (Resistance Temperature Detector) Terminal Board
engineered for seamless integration with GE’s industrial control systems—including the Mark VIe
DCS and Speedtronic™ turbine control platforms. As a critical signal interface component, it provides
secure, noise-immune connectivity between RTD sensors (used for precision temperature
measurement) and control system I/O modules. Designed to simplify wiring, enhance signal integrity,
and enable proactive diagnostics, this terminal board ensures accurate temperature monitoring in
harsh industrial environments—critical for applications where temperature fluctuations directly
impact equipment safety, efficiency, and uptime (e.g., turbine bearings, motor windings, process
pipelines).
Core Features
1. Versatile RTD Compatibility
Supports 2-, 3-, and 4-wire RTDs (PT100, PT1000, Cu-series) and auto-detects wire configuration—eliminating the need for separate terminal boards for different sensor types. Reduces spare parts inventory costs by up to 40%.
2. Precision Temperature Sensing
16-bit resolution and ±0.1% accuracy (at core operating range) ensure reliable temperature data for critical processes, such as turbine bearing temperature monitoring or chemical reactor thermal control. Built-in EMI filtering prevents signal corruption from nearby high-voltage equipment.
3. Industrial-Grade Durability
Conformal Coating: Protects internal components from moisture, dust, and chemical vapors (common in refineries or power plants), extending service life to 10+ years.
Flame-Retardant Housing: UL 94 V-0 rating meets strict fire safety standards for industrial cabinets.
Corrosion-Resistant Terminals: Gold-plated connectors maintain stable signal transmission even in humid or corrosive environments.
4. Seamless Mark VIe Integration
Plug-and-play design is automatically recognized by GE Mark VIe Configuration Studio—no custom wiring or calibration required. Cuts installation time by 30% compared to generic RTD terminal boards, accelerating system commissioning.
5. Proactive Diagnostics
LED status indicators (power: green; signal: amber; fault: red) enable instant troubleshooting (e.g., identify a disconnected RTD sensor in seconds). Built-in open/short-circuit detection alerts operators to sensor failures before they impact processes.
6. Hazardous Zone Readiness
ATEX/IECEx certification allows deployment in Zone 2 (flammable gas) and Zone 22 (combustible dust) areas—ideal for oil refinery pipe temperature monitoring, chemical plant reactor sensing, or grain processing facility thermal control.
Applications
Optimized for industries requiring precise RTD-based temperature monitoring with GE Mark VIe DCS:
Power Generation: Gas/steam turbine bearing temperature monitoring, boiler tube thermal sensing, transformer oil temperature control.
Oil & Gas: Pipeline fluid temperature tracking, wellhead thermal monitoring, refinery distillation column temperature sensing.
Chemical Processing: Reactor vessel temperature control, batch process thermal monitoring, heat exchanger temperature tracking.
Heavy Manufacturing: Steel mill rolling mill temperature sensing, cement plant kiln thermal monitoring, automotive paint oven temperature control.
Compatibility List
Category
Compatible Products
GE Mark VIe Components
IS200CPUH1A/IS200CPURH1A Controllers, IS200RTDH1A RTD Input Modules, IS200AEADH1A Analog I/O, IS200VCRCH1A Power Supplies
RTD Sensors
GE Industrial RTDs (PT100, PT1000), Siemens Sitrans T RTDs, ABB Temperature Sensors (Cu10/Cu50), Rosemount 644 RTD Transmitters
Software
GE Mark VIe Configuration Studio V9.0+, GE CIMPLICITY 11.0+ (for temperature data visualization), GE Proficy Historian (for data logging)
Why Choose GE IS210DRTDH1A
Genuine GE Quality: Engineered to match Mark VIe’s strict performance standards—avoids signal loss, compatibility errors, or premature failure common with third-party RTD terminal boards.
Cost Efficiency: Reduces inventory costs (versatile RTD support) and labor time (fast installation); 10-year lifespan lowers total cost of ownership (TCO) by 35% vs. generic alternatives.
Reliability: Field-proven design with millions of operating hours in global industrial facilities—ensures uninterrupted temperature monitoring for critical processes.
Global Support: Backed by GE’s 24/7 industrial service network—on-site technical support, 2-day spare parts delivery (North America/Europe), and remote troubleshooting via GE Digital Services.
Availability & Support
Stock Status: In stock (bulk orders of 5+ units qualify for 5–15% volume discounts)
