GE IS200RAPAG1BCA is a Turbine Module for Mark VIe systems, managing turbine operational parameters, executing control logic, and coordinating with other modules. It features real-time monitoring, diagnostics, operates at -40°C to +70°C, meets UL/CE, ensuring stable turbine performance.
accuracy, ensuring stable load matching with grid demands.
✅ Rugged Industrial Design: IPC-CC-830B Class 3 conformal coating and wide temperature tolerance
(-40°C to 70°C) for reliable operation in harsh turbine hall environments.
★Target Applications
Power Generation: Supplies stable multi-voltage DC to EX2100 excitation control racks in coal-fired, natural gas, and hydropower plants, safeguarding generator excitation stability.
Industrial Power: Powers Mark VIe racks for backup generator excitation in large manufacturing facilities, ensuring reliable startup and load matching during grid outages.
Renewable Energy: Supports Mark VIe synchronization modules in hybrid power plants, enabling generator output alignment with grid demands, with redundancy for continuity.
Marine: Delivers power to EX2100 racks for on-board generator excitation, with corrosion/vibration resistance to maintain stable shipboard power (navigation, propulsion).
Primary Application: Precision control of turbine speed, load, and safety functions in GE Mark VIe/EX2100 turbine control systems (for coal-fired, natural gas, hydropower, and industrial turbines)
2. Electrical Specifications
Input Signals:
Analog Inputs: 8 channels (4–20mA), for turbine speed (from speed sensors), inlet pressure, exhaust temperature, and oil pressure.
Discrete Inputs: 12 channels (24V DC), for safety interlocks (e.g., emergency stop, overspeed trip), valve position feedback, and system status signals.
Output Signals:
Analog Outputs: 6 channels (4–20mA), for governor valve control, fuel flow regulation, and pressure control actuators.
Discrete Outputs: 8 channels (24V DC), for safety valve triggers, alarm relays, and auxiliary equipment control.
Operating Voltage: 24V DC ±10% (powered via Mark VIe/EX2100 system backplane)
Power Consumption: <6W (typical operating condition)
