Schneider 140DDM39000 Input Output Module

Share to:

Schneider 140DDM39000 Input Output Module

Name: Schneider 140DDM39000 Input Output Module
Brand: Schneider
Rating: 5.0 (11 reviews)

Schneider 140DDM39000 is a Modicon Quantum 24VDC mixed I/O module, 16 sink inputs & 8 solid-state outputs, ≤1ms response, 4A max module load, short-circuit protection, ideal for fast, stable discrete control in heavy industry.

Availability:



Inquire Add to Basket

Model:
140DDM39000
Brand:
Schneider

140DDM39000 Schneider 140DDM39000 140DDM39000 Input Output Module Schneider PLC 140DDM39000 PLC 140DDM39000 PDF 140DDM39000 Datasheet

Product Description

Contact us directly!

Datasheet

Hot-selling

Specifications

Parameter	Details
Discrete Input Voltage	24 V DC
Discrete Output Voltage	24 V DC
Operating Ambient Temperature	0...60 °C
Storage Ambient Temperature	-40...85 °C
Voltage State 0 Guaranteed	-3...5 V
Voltage State 1 Guaranteed	15...30 V
Current State 0 Guaranteed	≤ 0.5 mA
Current State 1 Guaranteed	≥ 2 mA
Voltage Drop	0.4 V at 0.5 A

Key Functional Advantages

Flexible & Scalable I/O Configuration

Combines 16 discrete inputs (2 groups of 8) and 8 solid-state discrete outputs (2 groups of 4) for a

total of 24 I/O points, adapting to diverse discrete control needs. Sink logic for both inputs and

outputs ensures broad compatibility with industrial sensors, switches, and actuators, simplifying

system integration.

Precise & Reliable Signal Handling

Operates on 24 V DC (inputs and outputs) with well-defined voltage/current thresholds (state 0: -3–

5 V, ≤0.5 mA; state 1: 15–30 V, ≥2 mA) for accurate signal detection. Fast output response time (≤1

ms for both 0→1 and 1→0 transitions) enables real-time control for time-sensitive industrial

processes.

Robust Multi-Layer Protection

Features resistor-limited input protection and dual output safeguards (5 A fuses per group +

transient voltage suppression) to prevent damage from overloads, short circuits, and voltage

spikes. 500 Vrms inter-group isolation and 1780 Vrms group-to-bus isolation (for 1 minute) ensure

electrical safety and minimize interference.

Intuitive Diagnostics & Monitoring

Front-panel LEDs provide at-a-glance status feedback: green LEDs indicate active bus

communication and turned-on outputs; red LEDs alert to power loss, input faults, and

output faults. Simplifies troubleshooting and reduces maintenance downtime by enabling quick

identification of issues like blown fuses or lost field power.

Core Purpose & Application

The 140DDM39000 is a mixed discrete Input/Output (I/O) module specifically engineered for

Schneider Electric’s Modicon Quantum automation platform. Its primary purpose is to serve as a

reliable, high-performance interface between field-level devices (such as sensors, proximity

switches, limit switches, and small actuators) and Modicon Quantum controllers. By translating

discrete electrical signals from field sensors into digital data for the controller and converting

digital control commands from the controller into actionable outputs for actuators, the module

enables seamless bidirectional communication—forming the critical “bridge” that powers

discrete control logic in industrial automation systems. It is designed to deliver precise signal

handling, robust protection, and intuitive monitoring to ensure consistent operation of mission-

critical control workflows.
