Core Information of 140CRP81100R
140CRP81100R is inferred to be a variant of the 140CRP81100 Profibus communication module, likely
featuring enhanced reliability (e.g., ruggedized design, extended environmental tolerance, or
redundancy support) while retaining the core Profibus integration function for Quantum automation
controllers. It maintains compatibility with Quantum Unity CPUs and follows the same direct CPU
driver interface architecture for seamless industrial network integration.
●Model Number: 140CRP81100R
●Product Series: Schneider Electric Quantum Communication Modules (variant of 140CRP81100)
●Core Function: Serves as a Profibus interface for Quantum Unity CPUs, enabling data transmission
between the host controller and Profibus network devices. The "R" suffix typically indicates enhanced
robustness (e.g., ruggedized components, extended temperature range, or reliability-focused design)
for harsh industrial environments.
●Key Features: Direct CPU driver interface, local backplane support, no loadable software required for
Unity, and likely reinforced environmental or mechanical traits compared to the base model
140CRP81100.
●Application Scope: Industrial automation systems using Quantum Unity CPUs (140CPU31110,
140CPU43412A, 140CPU53414A/B), ideal for harsh or mission-critical Profibus networked scenarios
(e.g., heavy industry, outdoor installations, or high-vibration environments) requiring enhanced
module durability.
Operational Traits
●Software Requirement: No loadable software required for Unity environments; configurable via
Schneider’s industrial software (Unity Pro, Concept) to set Profibus parameters.
●Network Functionality: Enables the host Quantum CPU to communicate with Profibus
masters/slaves, distributed I/O modules, and other Profibus-compliant devices for control data
exchange and status monitoring.
●Integration: Leverages the Quantum backplane and CPU’s processing capabilities to integrate
seamlessly with local and distributed control tasks.
