GE IS200ISBEH1ABC is an ISBus Extender Board for Mark VI systems, extending ISBus communication range between modules. It boosts signal strength, ensures stable data transfer, operates at -40°C to +70°C, meets UL/CE, guaranteeing reliable long-distance ISBus connectivity.
1. Enhanced ISBus Range Extension with High Reliability
The IS200ISBEH1ABC is an advanced ISBus extender designed to expand the reach and capacity of GE’s ISBus communication networks in large-scale industrial control systems (e.g., power generation, turbine, and excitation systems). It regenerates and amplifies ISBus signals to support extended cable runs (up to 600 meters with shielded twisted-pair cable) and enables connection of more devices than standard ISBus segments, making it ideal for sprawling industrial facilities with distributed control components.
2. High-Speed Signal Regeneration & Integrity
Incorporates next-generation signal conditioning technology that regenerates ISBus data signals (up to 10 Mbps) with ultra-low latency (<0.5µs). This ensures minimal signal degradation over long distances, preventing data errors caused by attenuation, noise, or reflections—critical for maintaining real-time communication between remote I/O modules, controllers, and actuators in time-sensitive applications (e.g., turbine load control, generator excitation).
3. Increased Device Capacity & Flexible Topology
Supports multi-drop configurations with up to 64 ISBus-compatible devices per extended segment (double the capacity of predecessor models), reducing the need for multiple extenders in large systems. It also accommodates mixed topologies (daisy-chain, star) via configurable port settings, allowing system integrators to optimize wiring for specific facility layouts.
4. Dual Redundant Ports with Automatic Failover
Features dual independent ISBus ports (primary and secondary) with built-in redundancy logic. The board continuously monitors both ports for faults (e.g., cable breaks, signal loss) and automatically switches to the redundant path within <2ms, eliminating single points of failure and ensuring uninterrupted communication in mission-critical systems.
5. Advanced Diagnostic & Monitoring Capabilities
Real-Time Network Analytics: Measures signal strength, bit error rate (BER), and cable length, transmitting detailed metrics to the system HMI via ISBus or auxiliary Ethernet (optional) for remote monitoring. This enables predictive maintenance by identifying degrading network components (e.g., aging cables, loose connections).
Enhanced LED Indicators: Front-panel LEDs for power (green), port activity (primary/secondary: yellow), signal strength (bar graph), and fault status (red) provide granular visibility of network health, simplifying rapid troubleshooting.
Extended Fault Logging: Stores up to 100 time-stamped events (e.g., signal loss, overvoltage, high BER) with diagnostic codes, accessible via GE’s Proficy software for in-depth post-fault analysis.
6. Ruggedized for Extreme Industrial Environments
Environmental Protection: IPC-CC-830B Class 3 conformal coating with enhanced thickness (75µm) resists aggressive contaminants (oil mist, chemical fumes) in turbine halls, offshore platforms, or chemical plants.
Temperature & Humidity Range: Operates in -40°C to 85°C (-40°F to 185°F) and 5%–95% relative humidity (non-condensing), exceeding standard industrial ratings for harsh climates.
EMI/RFI Hardening: Complies with IEC 61000-6-4 (industrial emissions) and IEC 61000-6-2 (immunity), with reinforced shielding to resist interference from high-voltage equipment or radio transmitters.
7. Seamless Integration & Scalability
Broad Compatibility: Works with all ISBus-enabled GE systems, including Mark VIe, EX2100, and IS200-series modules, as well as legacy ISBus devices (backward compatibility with IS200ISBEH1ABB).
Plug-and-Play Design: Single-slot 3U Eurocard form factor with auto-detection of connected devices, enabling quick integration into existing GE control racks (e.g., IS200ERBPG1A) without manual configuration.
Power Efficiency: Operates on 24V DC ±10% from the system backplane, consuming <3.5W (typical) to minimize load on power supplies.
8. Safety & Compliance
Enhanced Isolation: 3kV AC galvanic isolation between input/output ports (higher than predecessor models) to prevent ground loops and protect against high-voltage transients.
Certifications: UL 61010-1, IEC 61800-5-1, ATEX Zone 2 (for hazardous areas), and CE compliance, ensuring global applicability in industrial and hazardous environments.
Surge & ESD Protection: Input/output ports withstand 4kV ESD (IEC 61000-4-2) and 2kV surge (IEC 61000-4-5), protecting against lightning-induced transients or electrostatic discharge.
