Products information
The HIMA F3225 is a safety-related multi-channel input module designed for industrial automation
and safety-critical systems (e.g., process control, emergency shutdown, and machinery safety),
compliant with CE certification and typical HIMA safety standards (likely aligning with IEC 61508 for
SIL 2/3 compatibility). It is engineered to reliably acquire signals from industrial sensors (such as
proximity switches, mechanical contacts, or analog sensors—consistent with HIMA’s 3000-series
focus on sensor integration) and features safe isolation between channels and power domains to
prevent cross-talk, electromagnetic interference (EMI), and ground loops—critical for maintaining
signal integrity in harsh industrial environments (e.g., oil & gas, chemical processing, and
manufacturing).
Like its series counterparts (F3221: 16-channel, F3222: 8-channel NAMUR), the F3225 likely offers a
fixed number of input channels (estimated 8–16 channels, optimized for medium-scale sensor
networks) and supports dedicated sensor power feeding (a common feature in HIMA input modules)
to eliminate the need for external power supplies for connected devices. It integrates real-time fault
detection (e.g., open-circuit, short-circuit, or overcurrent monitoring) and status indication (via front-
panel LEDs per channel) to enable quick troubleshooting.
For physical integration, the F3225 follows HIMA’s compact rack-mount design, requiring minimal
space (typically 4 SU/TE, consistent with F3221/F3222) for seamless installation in standard industrial
cabinets. It uses standardized cabling and connectors (e.g., HIMA’s Z-series front cable plugs) for
simplified wiring, and is compatible with HIMA’s PES (Programmable Electronic System) ecosystems
for centralized control and diagnostic integration.
Key Specifications
Parameter Category | Parameter | Estimated/Common Specifications (Consistent with HIMA 3000-Series Logic) |
Basic Information | Product Type | Safety-related multi-channel input module (likely 8–16 channels) for industrial sensors (mechanical contacts, proximity switches, or low-level analog signals) |
| Certification | CE compliant; IEC 61508 (SIL 2/3 compatible, typical for HIMA safety modules); EN 60947-5-6 (possible NAMUR support for proximity switches) |
| Safety Isolation | Channel-to-channel isolation: ≥2.5 kV AC (1 min); Channel-to-ground isolation: ≥2 kV AC (1 min) |
Electrical Specifications | Input Compatibility | - Digital input: 24 V DC mechanical contacts, NAMUR proximity switches (1.2–2.1 mA switching range)- Possible analog input: 0–10 V DC / 4–20 mA (if supporting analog sensors) |
| Sensor Power Feeding | Dedicated sensor supply: 7.7–9 V DC (for NAMUR switches) or 24 V DC (for mechanical contacts) |
| Power Supply Requirements | - 5 V DC: 40–70 mA (logic power, consistent with F3221/F3222)- 24 V DC: 75–130 mA (sensor power and module operation) |
| Switching Performance | - Switching time: ~10 ms (typical for HIMA input modules)- Switching point (for NAMUR): 1.65 mA ± 0.2 mA (if applicable) |
| Fault Detection | Open-circuit/short-circuit monitoring per channel; overcurrent protection for sensor feeding |
Mechanical Specifications | Number of Channels | 8–16 independent input channels (medium-scale integration) |
| Space Requirement | 4 SU (Terminal Equipment units) or 4 TE (consistent with F3221/F3222) |
| Cabling & Connectors | - Cable type: LiYY 16×0.5 mm² (screened, for EMI mitigation)- Front cable plug: HIMA Z-series (e.g., Z7108/Z7116, lead marking: Z xxx/3225/C..)- Flat pin plug: 2.8×0.8 mm² (power/ground connections) |
Functional Features | Status Indication | Front-panel LEDs per channel (green: normal, red: fault, amber: signal active) |
| Diagnostic Integration | Compatible with HIMA central modules (e.g., F8650/F8651) via I/O bus for centralized fault logging |
| Environmental Resistance | Operating temperature: -20°C to +60°C; Relative humidity: 10–90% (non-condensing) |
