1756-DNB/D Advantages
The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module stands out from comparable network modules in several key areas.
Dedicated DeviceNet scanner function. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module acts as network scanner, the Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module can scan DeviceNet slave nodes and route data between ControlLogix backplane and DeviceNet network.
Selectable DeviceNet communication baud rates. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module supports 125 kbps, 250 kbps and 500 kbps baud rate options to match different DeviceNet network layout and cable length requirements.
Native ControlLogix backplane integration. As a factory‑original communication module of Allen‑Bradley 1756 series, the Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module directly plugs into 1756 chassis, no extra conversion adapter required.
Comprehensive diagnostic LED indication. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module is equipped with LEDs for module status, network status and fault status, technicians can quickly locate fault points of the Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module without complex diagnostic tools.
Convenient configuration via RSLogix 5000. Users can configure node address, baud rate and scanned slave device list for the Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module inside RSLogix 5000 software, supporting online edits and network monitoring.
1756-DNB/D Applications
DeviceNet Field I/O Network Integration. DeviceNet scanner module within Allen‑Bradley 1756 ControlLogix PLC systems, the Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module connects ControlLogix controllers to DeviceNet slave I/O blocks, sensors and actuators.
Variable Frequency Drive and Smart Device Networking. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module enables communication between ControlLogix CPU and DeviceNet‑enabled drives, motor starters and other smart automation devices.
Legacy DeviceNet Automation System Maintenance. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module is stocked as spare replacement part for existing ControlLogix DeviceNet networks.
Assembly Line and Material Handling Control. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module is widely used in packaging, conveyor and assembly systems that adopt DeviceNet fieldbus.
Industrial Automation Turnkey Project Fieldbus Networking. The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module serves as standard DeviceNet scanner interface for ControlLogix automation solutions.
1756-DNB/D Certifications & Compliance
The Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module holds the following international safety and compliance approvals:
• UL listed — North‑American industrial control equipment safety approval.
• CE certification — European industrial control equipment safety and EMC compliance.
• C‑Tick marked — EMC compliance for Australian and New Zealand markets.
• Class I Division 2 certified — Suitable for installation in specified hazardous classified locations.
All modules supplied are 100% new original Allen‑Bradley parts. Every Allen‑Bradley 1756‑DNB/D ControlLogix DeviceNet Scanner Module unit is functionally tested before dispatch, packed in professional anti‑static packaging, and covered by a one‑year warranty from the date of delivery.
