1756-ENBT Advantages
The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module stands out from comparable communication modules in several key areas.
Single‑port 10/100Mbps auto‑negotiate EtherNet/IP capability. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module provides RJ45 copper Ethernet port, the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module supports auto‑negotiation of communication speed for standard factory network layouts.
Sufficient connection resource support. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module supports up to 128 CIP connections and 64 TCP connections, the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module meets conventional distributed I/O and multi‑device message transmission requirements.
Native ControlLogix backplane integration. As a factory‑original communication module of Allen‑Bradley 1756 series, the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module directly plugs into 1756 chassis, no extra conversion adapter required.
Comprehensive diagnostic LED indication. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module is equipped with LEDs for module status, link status, network activity and fault status, technicians can quickly locate fault points of the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module without complex diagnostic tools.
Convenient configuration via RSLogix 5000. Users can configure IP address and CIP connection parameters for the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module inside RSLogix 5000 software, supporting online edits and network monitoring.
1756-ENBT Applications
Standard‑Environment EtherNet/IP Field I/O Networking. EtherNet/IP bridge module within Allen‑Bradley 1756 ControlLogix PLC systems, the Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module connects ControlLogix controllers to EtherNet/IP remote I/O blocks, sensors and actuators inside general industrial cabinets.
Variable Frequency Drive and Smart Device Networking. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module establishes communication between ControlLogix CPU and EtherNet/IP‑enabled drives and smart field devices for factory automation equipment.
Legacy ControlLogix EtherNet/IP System Maintenance. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module is stocked as spare replacement part for existing ControlLogix EtherNet/IP networks.
Assembly Line and Material Handling Control. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module is widely used in packaging, conveyor and assembly systems that adopt EtherNet/IP fieldbus.
Industrial Automation Turnkey Project Fieldbus Networking. The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module serves as standard single‑port EtherNet/IP bridge interface for general‑purpose ControlLogix automation solutions.
1756-ENBT Certifications & Compliance
The Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module holds the following international safety and compliance approvals:
• UL listed — North‑American industrial control equipment safety approval.
• CE certification — European industrial control equipment safety and EMC compliance.
• C‑Tick marked — EMC compliance for Australian and New Zealand markets.
• Class I Division 2 certified — Suitable for installation in specified hazardous classified locations.
All modules supplied are 100% new original Allen‑Bradley parts. Every Allen‑Bradley 1756‑ENBT ControlLogix EtherNet/IP Bridge Module unit is functionally tested before dispatch, packed in professional anti‑static packaging, and covered by a one‑year warranty from the date of delivery.
