GE IS200EMCSG1AAB Conduction Sensor Board: Comprehensive Product Overview
The GE IS200EMCSG1AAB is a specialized Conduction Sensor Board engineered exclusively for GE’s
EX2100 excitation control system, serving as a critical monitoring and protection component for
silicon-controlled rectifiers (SCRs) in generator/motor excitation circuits. Its core function is to detect
and verify the conduction status of SCRs—key components that regulate DC excitation current—by
monitoring voltage drop across SCRs during operation, ensuring they switch on/off as intended to
prevent overcurrent, overheating, or excitation system instability. Unlike generic sensor boards, it
integrates dual-channel monitoring (supporting parallel SCR configurations common in high-power
excitation systems), real-time fault detection (e.g., SCR misfiring, open circuits), and direct
communication with the EX2100’s DSPX master controller via the EISB (Exciter Internal Serial Bus).
This enables instant alarm triggering and protective actions (such as de-excitation) if abnormal
conduction is detected, avoiding catastrophic damage to excitation windings or SCR modules.
Designed as a compact single-slot, 3U form factor module, it mounts seamlessly in EX2100 control
racks, with a ruggedized PCB coated to IPC-CC-830B standards to resist dust, moisture, and chemical
contaminants in industrial environments. The board features front-panel LED indicators (one per
monitoring channel) for at-a-glance status checks (green = normal conduction, red = fault),
simplifying on-site troubleshooting. It operates with a 24V DC backplane power supply and supports
a wide input voltage range (0–1000V DC) to accommodate varying SCR voltage drops in low- to high-
power excitation systems (from 500kVA backup generators to 1000MVA utility-scale generators).
Whether deployed in thermal power plants, steel mill motor excitation systems, or petrochemical
captive power facilities, the IS200EMCSG1AAB acts as a “safety sentinel” for SCR conduction,
ensuring reliable and safe operation of the entire excitation system.
Detailed Specification Table
Category
Details
Core Function
Monitors SCR conduction status in EX2100 excitation systems; detects SCR misfiring/open circuits; triggers alarms/protective actions; communicates with DSPX controller via EISB.
Mechanical Specifications
Single-slot, 3U form factor; compatible with EX2100 control racks; front-panel LED indicators (2 channels); conformal-coated PCB (IPC-CC-830B).
Electrical Parameters
Power supply: 24V DC (from system backplane); input voltage range: 0–1000V DC (for SCR voltage drop monitoring); 2 independent monitoring channels.
Environmental Ratings
Operating temperature: -40°C to 70°C; storage temperature: -55°C to 85°C; relative humidity: 5%–95% (non-condensing); EMI/RFI immune (via shielded traces).
Communication & Control
EISB (Exciter Internal Serial Bus) interface for DSPX controller; real-time fault signal output (dry contact for external alarms); LED status for channel health.
System Compatibility
GE EX2100 excitation control system; DSPX master controller; SCR modules (GE or compatible); EX2100 EISB bus; simplex/redundant excitation configurations.
Installation & Maintenance
Hot-swappable in redundant setups; no external jumpers (software-configurable thresholds); front-panel LEDs for quick diagnostics; tool-free rack mounting.
Key Applications
Thermal/hydropower generator excitation SCR monitoring; steel mill DC motor excitation SCRs; petrochemical captive power plant excitation systems; backup generator excitation control.
Compliance & Documentation
Aligns with GE EX2100 series standards; technical specs in GEH-6632 (EX2100 User’s Guide); CE/UL certified; typical 12-month warranty.
