1769-L18ER-BB1B Advantages
The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller stands out from comparable CompactLogix controllers in several key areas.
Integrated embedded digital I/O. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller is equipped with 16 sinking DC inputs and 16 sourcing DC outputs, reducing the external I/O module count for compact machine projects.
Dual‑port EtherNet/IP with DLR support. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller provides two Ethernet ports supporting Device‑Level Ring topology, improving network fault tolerance for machine automation.
POINT‑bus flexible I/O expansion. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller supports up to 8 POINT‑bus expansion modules, allowing incremental I/O scaling according to application requirements.
Included 1 GB SD card for program backup. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller ships with a 1 GB SD card, supporting project backup, restore, and firmware update without extra accessories.
Unified Logix programming environment. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller uses standard Studio 5000 / RSLogix 5000 tag‑based programming, sharing the same programming workflow as larger ControlLogix platforms.
Clear multi‑status LED indicators. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller features dedicated LEDs for run, fault, force, and I/O status, assisting maintenance technicians with rapid on‑site fault diagnosis.
1769-L18ER-BB1B Applications
Packaging machine integrated control. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller is a dedicated compact Logix controller within Allen‑Bradley CompactLogix 5370 POINT‑bus systems, executing logic for feed, sealing, and sorting functions on small and medium packaging equipment.
Conveyor and material handling automation. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller manages embedded I/O plus POINT‑bus expansion I/O for compact conveyor lines, communicating with HMI and variable speed drives over EtherNet/IP.
Skid‑mounted pump and valve package control. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller delivers compact, network‑ready sequence control for process skid units in water treatment and fluid handling applications.
Legacy CompactLogix 5370 System Spare Replacement. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller is stocked as a spare replacement unit for existing POINT‑bus CompactLogix 5370 control installations.
Standalone special purpose machinery control. The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller provides integrated control for textile, woodworking, and auxiliary production machines that require built‑in Ethernet networking.
1769-L18ER-BB1B Certifications & Compliance
The Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller holds the following international safety and compliance approvals:
UL listed — North American industrial control equipment safety approval.
CE certification — European industrial control equipment safety and EMC compliance.
C‑Tick marked — EMC compliance for Australian and New Zealand markets.
Class I Division 2 certified — Suitable for installation in specified hazardous classified locations.
All units supplied are 100% new original Allen‑Bradley parts. Every Allen‑Bradley 1769‑L18ER‑BB1B CompactLogix Controller unit is functionally tested before dispatch, packed in professional anti‑static packaging, and covered by a one‑year warranty from the date of delivery.
